Docker and Kubernets

Sharad included in Documentation
   2212 words   11 minutes

Docker

Install Docker

Install Docker: Windows

Use the following URL and download the installation file: https://hub.docker.com/editions/community/docker-ce-desktop-windows

Install Docker: Linux

Use the following URL and download the installation file: https://hub.docker.com/editions/community/docker-ce-desktop-windows

Install Docker: Mac

Use the following URL and download the installation file: https://hub.docker.com/editions/community/docker-ce-desktop-windows

Commands

$ docker version // docker version

ps – list containers

1
2

  docker ps
  docker ps -a

Stop container

1

  docker stop [name of container]

Remove a container

1

docker rm [name of container]

List images

1

docker images

Remove images

1

docker rmi nginx   ///! Delete all dependent containers to remove image

Download image

1

docker run nginx

1

docker pull nginx

Exec – execute a command

1
2

docker exec <<name of image>> cat /etc/hosts
Run – attach and detach
1

docker run kodekloud/simple-webapp

1

docker run –d kodekloud/simple-webapp
Run – tag
1

docker run redis:4.0 TAG

1

docker run –i kodekloud/simple-prompt-docker

/conainerization/port-mapping.png
Port Mapping

Run volume mapping

1

docker run –v /opt/datadir:/var/lib/mysql mysql

/conainerization/volume-mapping.png

Inspect container
1

docker inspect <<container name>>
Container’s log
1

docker logs <<container name>>
Environment variable
1

docker run -e APP_COLOR=blue simple-webapp-color

` Dockerfile

1
2
3
4
5
6
7

FROM Ubuntu   #OS - Ubuntu
RUN apt-get update  #Update apt repo
RUN apt-get install python    #Install dependencies using apt
RUN pip install flask      #Install Python dependencies using pip
RUN pip install flask-mysql
COPY . /opt/source-code     #Copy source code to /opt folder
ENTRYPOINT FLASK_APP=/opt/source-code/app.py flask run  #Run the web server using “flask” command

1
2

docker build Dockerfile –t mmumshad/my-custom-app
docker push mmumshad/my-custom-app D

List volumns

docker list volumne docker rm [volumne]

Docker Networking

Docker provides different network settings for Linux and Windows.

For Linux, there are six pre-configured network options:

  1. Bridge
  2. Host
  3. Overlay
  4. IPvLan
  5. MACvLan
  6. None

For Windows, there are six pre-configured network options:

  1. NAT (Network Address Translation)
  2. Transparent
  3. Overlay
  4. L2Bridge
  5. L2Tunnel
  6. None You choose which of these network configurations to apply to your container depending on its network requirements.

Kubernetes

https://github.com/zealvora/certified-kubernetes-application-developer

Kubectl

kubectl, allows you to run commands against Kubernetes clusters. Install kubectl https://kubernetes.io/docs/tasks/tools/

KIND
Minikube

https://minikube.sigs.k8s.io/docs/start/

Lets you run Kubernetes locally

1
2
3

minikube start
minikube start --vm-driver hyperv --hyperv-virtual-switch "Default Switch"
kubectl get nodes

Open minikube dashboard minikube dashboard

Kubernetes on AWS

EKS ( Elastic Kubernets Service)

Install KubeCtl

Reference: https://docs.aws.amazon.com/eks/latest/userguide/install-kubectl.html

Primary scalar types

  • Create Cluster
1

eksctl create cluster --name=eksdemo1 --region=us-east-1 --zones=us-east-1a,us-east-1b --without-nodegroup
  • Get List of clusters
1

eksctl get cluster
  • Step-02: Create & Associate IAM OIDC Provider for our EKS Cluster To enable and use AWS IAM roles for Kubernetes service accounts on our EKS cluster, we must create & associate OIDC identity provider. To do so using eksctl we can use the below command. Use latest eksctl version (as on today the latest version is 0.21.0)

Template

1
2
3
4

eksctl utils associate-iam-oidc-provider \
    --region region-code \
    --cluster <cluter-name> \
    --approve

Replace with region & cluster name

1

eksctl utils associate-iam-oidc-provider   --region us-east-1   --cluster eksdemo1   --approve
  • Step-03: Create EC2 Keypair Create a new EC2 Keypair with name as kube-demo This keypair we will use it when creating the EKS NodeGroup. This will help us to login to the EKS Worker Nodes using Terminal. Step-04: Create Node Group with additional Add-Ons in Public Subnets These add-ons will create the respective IAM policies for us automatically within our Node Group role.
  • Create Public Node Group
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

eksctl create nodegroup --cluster=eksdemo1 \
                       --region=us-east-1 \
                       --name=eksdemo1-ng-public1 \
                       --node-type=t3.medium \
                       --nodes=2 \
                       --nodes-min=2 \
                       --nodes-max=4 \
                       --node-volume-size=20 \
                       --ssh-access \
                       --ssh-public-key=kube-demo \
                       --managed \
                       --asg-access \
                       --external-dns-access \
                       --full-ecr-access \
                       --appmesh-access \
                       --alb-ingress-access

eksctl create nodegroup --cluster=eksdemo1 --region=us-east-1 --name=eksdemo1-ng-public1 --node-type=t3.medium --nodes=2 --nodes-min=2 --nodes-max=4 --node-volume-size=20 --ssh-access --ssh-public-key=ekc-ecs-demo-2022 --managed --asg-access --external-dns-access --full-ecr-access --appmesh-access --alb-ingress-access

Step-05: Verify Cluster & Nodes

  • List EKS clusters eksctl get cluster

  • List NodeGroups in a cluster eksctl get nodegroup --cluster=<clusterName>

  • List Nodes in current kubernetes cluster kubectl get nodes -o wide

Our kubectl context should be automatically changed to new cluster

kubectl config view –minify

AKS (Azure Kubernetes Service)

AKS

1
2

az login
az aks install-cli
  • Get k8s available versions

az aks get-versions --location $REGION -o table

  • To configure kubectl to connect to your Kubernetes cluster
    1

    az aks get-credentials --resource-group $RESOURCE_GROUP --name $CLUSTER_NAME

1
2
3

* List Kubernetes Worker Nodes
kubectl get nodes
kubectl get nodes -o wide
  • List Namespaces
1
2

kubectl get namespaces
kubectl get ns
  • List Pods from all namespaces
1

kubectl get pods --all-namespaces
  • List all k8s objects from Cluster Control plane
1

kubectl get all --all-namespaces
  • Open k8s Dashboard
1

az aks browse --resource-group $RESOURCE_GROUP --name $CLUSTER_NAME
  • If you’re using RBAC enabled kubernetes cluster, you need to configure Service Account and RoleBinding in order to make Dashbaord work.Here is a way to give full privilege (role: cluster-admin) to the Dashboard’s Service Account kubernetes-dashboard
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

    # Here is a way to give full privilege (role: cluster-admin) to the Dashboard’s Service Account kubernetes-dashboard
    $ cat <<EOF | kubectl apply -f -
    apiVersion: rbac.authorization.k8s.io/v1beta1
    kind: ClusterRoleBinding
    metadata:
    name: kubernetes-dashboard
    labels:
        k8s-app: kubernetes-dashboard
    roleRef:
    apiGroup: rbac.authorization.k8s.io
    kind: ClusterRole
    name: cluster-admin
    subjects:
    - kind: ServiceAccount
    name: kubernetes-dashboard
    namespace: kube-system
    EOF

  • Get cluster Info az aks show --resource-group $RESOURCE_GROUP --name $CLUSTER_NAME -o table

  • Get Node group info az aks show --resource-group $RESOURCE_GROUP --name $CLUSTER_NAME --query nodeResourceGroup -o tsv *Scale AKS Cluster nodes az aks scale --name $CLUSTER_NAME --resource-group $RESOURCE_GROUP --node-count $NODE_COUNT Upgrade AKS Cluster version az aks upgrade --name $CLUSTER_NAME --resource-group $RESOURCE_GROUP --kubernetes-version $KUBERNETS_VERSION

  • Check which Kubernetes releases are available for upgrade for your AKS cluster az aks get-upgrades –name $CLUSTER_NAME –resource-group $RESOURCE_GROUP -o table

Enable Add-on

  • Enable Azure Monitor for Containers OMS_WORKSPACE_RESOURCE_ID="/subscriptions/87c7c7f9-0c9f-47d1-a856-1305a0cbfd7a/resourceGroups/DefaultResourceGroup-EJP/providers/Microsoft.OperationalInsights/workspaces/DefaultWorkspace-77c7c7f9-0c9f-47d1-a856-1305a0cbfd7a-EJP" az aks enable-addons -a monitoring --name $CLUSTER_NAME --resource-group $RESOURCE_GROUP --workspace-resource-id $OMS_WORKSPACE_RESOURCE_ID

  • Enable HTTP Application Routing az aks enable-addons --addons http_application_routing --name $CLUSTER_NAME --resource-group $RESOURCE_GROUP

  • Check egress IP kubectl run -it --rm runtest --image=debian --generator=run-pod/v1 pod> apt-get update && apt-get install curl -y pod> curl -s checkip.dyndns.org

ACR

  • Create an Azure Container Registry az acr create --resource-group $RESOURCE_GROUP --name $ACR_NAME --sku Basic SKU: Basic, Standard, Premium, Classic

  • Get ACR list az acr list -o table

  • Get ACR Detail az acr show -n $ACR_NAME -g $RESOURCE_GROUP

  • Get only ACR ID az acr show -n $ACR_NAME -g $RESOURCE_GROUP --query "id" -o tsv

  • Show ACR Repositories

  • Show list of repositories az acr repository list -n $ACR_NAME -o table
  • Show the detail of a repository az acr repository show -n $ACR_NAME --repository $REPO_NAME -o table
  • Show list of tags in a repository az acr repository show-tags -n $ACR_NAME --repository $REPO_NAME -o table
  • Login to ACR az acr login --name $ACR_NAME
  • Alternatively login with docker command

ACR_LOGIN_SERVER=$ACR_NAME.azurecr.io docker login $ACR_LKOGIN_SERVER -u $ACR_USER -p $ACR_PASSWORD

  • ACR Task - Build az acr build --registry $ACR_NAME --image [CONTAINER_NAME:TAG] [SOURCE_LOCATION]
  • More usages are:
  • Queue a local context (folder), pushed to ACR when complete, with streaming logs. az acr build -t sample/hello-world:{{.Run.ID}} -r MyRegistry .
  • Queue a local context, pushed to ACR without streaming logs. az acr build -t sample/hello-world:{{.Run.ID}} -r MyRegistry --no-logs .
  • Queue a local context to validate a build is successful, without pushing to the registry using the –no-push parameter. az acr build -t sample/hello-world:{{.Run.ID}} -r MyRegistry --no-push .
  • Queue a local context to validate a build is successful, without pushing to the registry. Removing the -t parameter defaults to –no-push az acr build -r MyRegistry .

AKS|ACR|AzureDevops Complete Reference Architecture

https://learn.microsoft.com/en-us/azure/architecture/reference-architectures/containers/aks-microservices/images/aks.svg

AKS Features and References articles

Service Principal
Authn and Authz
  • 3 options to manage access and identity for AKS clusters
    • Azure RBAC (integration with Azure AD) to control the access to AKS
      1
2
3
4
5
6

      1. Developer authenticates with Azure AD(AAD).
2. AAD token issuance endpoint issues the access token.
3. The developer performs an action using the AAD token, such as kubectl create pod
4. k8s validates the token with AAD and fetches the developer's group memberships.
5. k8s RBAC and cluster policies are applied.
6. Developer's request is successful or not based on previous validation of AAD group membership and k8s RBAC and policies.
      from Bast pracitses for authn & authz in AKS
    • Kubernetes RBAC
    • Pod Identities
      • Use managed identities for Pods in AKS to access to Azure resources
        • Managed Identities let you automatically request access to services through Azure AD. You don’t manually define credentials for pods, instead they request an access token in real time (See azure doc)
      • Use Pod Identities(Managed Identity)
Cluster Security
Data Volume
Network Plugin
  • kubenet (default policy)
    • az aks create –network-plugin option: kubenet
    • see also k8s.io
  • Azure CNI
    • az aks create –network-plugin option: azure
Network Policiy
  • Kubernetes version: 1.12+
  • Network Policy Recipes
  • Network policy Options in AKS
      1. Azure Network Policies - the Azure CNI sets up a bridge in the VM host for intra-node networking. The filtering rules are applied when the packets pass through the bridge
      • az aks create –network-plugin azure
      1. Calico Network Policies - the Azure CNI sets up local kernel routes for the intra-node traffic. The policies are applied on the pod’s network interface.
      • see [the difference between the two](the Azure CNI sets up local kernel routes for the intra-node traffic. The policies are applied on the pod’s network interface.)
      • az aks create –network-plugin azure && –network-policy calico
Load Balancer
  • Service: type=LoadBalancer (NOT ClusterIP nor NodePort)
  • Default: External Load balancer
  • Static IP to LB (see azure doc)
    1
2
3
4
5
6
7

    apiVersion: v1
kind: Service
metadata:
    name: servicename
spec:
    loadBalancerIP: 41.222.222.66
    type: LoadBalancer
  • Internal Load balancer - Only accessible from the same VNET
    • Annotation for Internal LB
      1
2
3
4
5
6
7
8
9

      apiVersion: v1
kind: Service
metadata:
    name: servicename
    annotations:
        service.beta.kubernetes.io/azure-load-balancer-internal: "true"
spec:
    type: LoadBalancer
    ...
    • You can specify IP address for LB: loadBalancerIP:XX.XX.XX.XX
    • You can specify a subnet for LB with special annotation
      1
2
3

      annotations:
    service.beta.kubernetes.io/azure-load-balancer-internal: "true"
    service.beta.kubernetes.io/azure-load-balancer-internal-subnet: "apps-subnet"
Ingress
Egress
  • Static IP for egress traffic
    • See azure doc
    • Default: egress IP from AKS is randomly assigned

      Once a Kubernetes service of type LoadBalancer is created, agent nodes are added to an Azure Load Balancer pool. For outbound flow, Azure translates it to the first public IP address configured on the load balancer. This public IP address is only valid for the lifespan of that resource. If you delete the Kubernetes LoadBalancer service, the associated load balancer and IP address are also deleted.

    • Procedures
        1. Create static IP in AKS node resource Group
        1. Create a service with the static IP ( put the static IP to the loadBalancerIP property)
DNS
Autoscale
GPU nodes
Quota and Limits for AKS
Troubleshooting
Azure Container Registory (ACR)
  1. Create a resource group
1

az group create --name devopresources --location westeurope
  1. Create ACR (Azure container repository)
1

az acr create --resource-group devopresources --name devopsshoppingacr --sku Basic
  1. Enable admin access on the ACR repor
1

az acr update --resource-group devopresources --n devopsshoppingacr --admin-enabled true

1 Requirements

eyteyhdhgh Thanks to the simplicity of Hugo, Hugo is the only dependency of this theme.

Just install latest version of  Hugo (> 0.84.0) for your OS (Windows, Linux, macOS).

Why not support earlier versions of Hugo?
Since Markdown Render Hooks was introduced in the Hugo Christmas Edition and some of image resources are using webp which was introduced in 0.84.0, this theme only supports Hugo versions above 0.84.0.
Hugo extended version is recommended
Since some features of this theme need to processes  SCSS to  CSS, it is recommended to use Hugo extended version for better experience.

2 Installation

The following steps are here to help you initialize your new website. If you don’t know Hugo at all, we strongly suggest you learn more about it by following this great documentation for beginners.

2.1 Create Your Project

Hugo provides a new command to create a new website:

1
2

hugo new site my_website
cd my_website

testigggg

Updated on 2023-12-15  7501b95
Read Markdown
 docker, kubernets, container, microservice
Back | Home
